Output shaft power1 | 1.88 hp |
Cylinder displacement | 38 cm³ |
Torque, max. | 1.9 Nm |
Torque, max. at rpm | 7,000 rpm |
Chain speed at max power | 55 fts |
Clutch engagement speed (±120) | 4,000 rpm |
Electrode gap | 0.022 in |
Idling speed | 3,000 rpm |
Ignition module air gap | 0.01 in |
Maximum power speed | 9,000 rpm |
Oil pump type | Automatic |
Spark Plug | Husqvarna HQT-1 |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Equipment | |
Recommended bar length, min | 14 in |
Pitch | 3/8" mini |
Recommended bar length, max | 18 in |
Chain type | S93G |
Bar length | 40 cm |
Bar length (inch) | 16 in |
Sprocket type | Rim 6 |
Gauge | .050" |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Dimensions | |
Weight (excl. cutting equipment) | 10.7 lbs |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Sound and noise | |
Sound pressure level at operators ear (LpA) | 95 dB(A) |
Sound power level, guaranteed (LWA) | 116 dB(A) |
Sound power level, measured | 113 dB(A) |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Vibration | |
Equivalent vibration level (ahv, eq) rear handle | 5.9 m/s² |
Equivalent vibration level (ahv, eq) front handle | 4.4 m/s² |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Lubricant | |
Oil tank volume | 0.32 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| 16", 3/8 pitch, .050 ga. 38cc chainsaw FA CraftBx970 73 96‑16 | |
|---|---|
| Emission | |
Exhaust emissions (CO₂ EU V)2 | 957 g/kWh |
